TH-86EQ1

86" Professional Display Panel

Highlights

  • 4K Ultra HD 86”, thin and stylish appearance
  • Ultra HD resolution 3,840 x 2,160
  • Easy installation and high connectivity, suitable for corporate and retail environment

Features

Specifications


86" Professional Display Panel
Professional Display Panels
Display Panel
Screen Size (Diagonal)86-inch (2175mm)
Aspect Ratio16:9
Panel TypeIPS Panel/E-LED
Effective Display Area (W x H)1895 x 1065 mm (74.6" x 41.9")
Resolution3840 x 2160 pixels
Brightness (Typ)350 cd/m2
Contrast Ratio1400:1
Response Time (G to G)8 ms (G to G)
Viewing Angle (Horizontal/Vertical)178°
Terminal
HDMI InHDMI TYPE-A Connector x 2
VIDEO In4-pole Mini Jack (M3) x 1
Audio In (L/R)Stereo Mini Jack (M3) x 1 (Shared with DVI-D In)
DVI-D InDVI-D 24-pin x 1
PC InMini D-sub 15-pin x 1
Serial In/OutDVI-D 9-pin x 1, RS-232C Compatible
LAN In/OutRJ45 x 1, 10 BASE-T / 100 BASE-TX / 1000 BASE-T (TBD), Compatible with PJLinkTM
IR InMini Jack (M3) x 1 / x 1
IR OutMini Jack (M3) x 1 / x 1
USBUSB Connector (Type A) x 1, DC 5V/2A (USB 3.0 supported)
Audio
Built in Speakers20 W [10W + 10W]
Electrical
Power Requirements110-127V AC 50/60 Hz, 220-240V AC 50/60 Hz
Power ConsumptionTBD
Power Off ConditionApprox. 0.3 W
Stand-by ConditionApprox. 0.5 W
General
Dimensions (W x H x D) (mm)1928 x 1099 x 76mm (75.9" x 43.3" x 3.0")
Weight (kg)64 kg (141.1 lbs.)
Bezel Width15.2 mm (all) (0.60")
Bezel to Bezel-
Pitch for Wall-Hanging600 x 400 mm (23.6" x 15.7")
Operating EnvironmentTBD

This Product Catalogue of online version is for reference only. If there are any errors or omissions, the specifications produced by the factory shall prevail.

Shun Hing Electronic Trading Co., Ltd. reserves the right of changing product design and specification without notice.

In case of any dispute, Shun Hing Electronic Trading Co., Ltd. reserves the right of final decision.
